Product Specifications - HFD2175 - Eaton Molded Case Circuit Breaker
-
Part Number:
HFD2175 -
Manufacturer:
-
Family:
Series C -
Pole:
2 -
Amp
175 -
Volt:
600 -
Phase:
1
-
Category:
-
Connection:
Bolt-On -
Type:
HFD -
Functions:
LI - Long-Time and Instantaneous -
Protection:
Thermal Magnetic -
AIC Ratings:
65kA@480V -
Frame Type:
F Frame
Dimensions
-
Dimensions (HxWxD):
5" x 3.5" x 7.5"
-
Weight:
3 lbs
Standards
Product Description - HFD2175 - Eaton Molded Case Circuit Breaker
Eaton Cutler Hammer, Series C, type HFD, 2P, 1PH, 175A, 600V, 65kA@480V, high interrupting capacity, 40CbF bolt-on complete with non-interchangeable LI - Long-Time and Instantaneous trip functions and load side lug terminals thermal magnetic molded case circuit breakers
