Product Specifications - HDA260351 - Schneider Electric Molded Case Circuit Breakers
-
Part Number:
HDA260351 -
Manufacturer:
-
Family:
Powerpact -
Pole:
2 -
Amp
35 -
Volt:
600 -
Phase:
1
-
Category:
-
Connection:
I-Line Style Plug-In -
Type:
H Frame -
Functions:
LI - Long-Time and Instantaneous -
Protection:
Thermal Magnetic -
AIC Ratings:
18kA@480V
Dimensions
-
Dimensions (HxWxD):
3.39 x 4.09 x 6.42 -
Weight:
4.85 lb
Standards
Product Description - HDA260351 - Schneider Electric Molded Case Circuit Breakers
Introducing the HDA260351 by Square D, a 2-pole (2P) molded case circuit breaker within the Powerpact series. Configured for A & B phase connection and designed for single-phase (1PH) applications, it features a 35A rating at 600V. With a standard interrupting capacity of 18kA@480V, it is UL listed and adopts the I-Line Style Plug-In installation. Complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, and load side lug terminals, this Thermal Magnetic molded case circuit breaker ensures efficient electrical protection.
