$221.40The Story
Overview
Product Specifications - HDA261254 - Schneider Electric Molded Case Circuit Breakers
-
Part Number:
HDA261254 -
Manufacturer:
-
Family:
Powerpact -
Pole:
2 -
Amp
125 -
Volt:
600 -
Phase:
1
-
Category:
-
Connection:
I-Line Style Plug-In -
Type:
H Frame -
Functions:
LI - Long-Time and Instantaneous -
Protection:
Thermal Magnetic -
AIC Ratings:
18kA@480V
Dimensions
-
Dimensions (HxWxD):
3.39 x 4.09 x 6.42 -
Weight:
4.85 lb
Standards
Product Description - HDA261254 - Schneider Electric Molded Case Circuit Breakers
This Square-D Powerpact circuit breaker is designed for 1-phase (1PH) applications with a 2-pole (2P) configuration. Configured for B & C phase connection, it boasts a high 125A rating at 600V, featuring a standard interrupting capacity of 18kA@480V. UL listed and suitable for reverse fed applications, it ensures reliable electrical protection. The breaker is complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, adhering to Thermal Magnetic principles.
Description
Overview
Product Specifications - HDA261254 - Schneider Electric Molded Case Circuit Breakers
-
Part Number:
HDA261254 -
Manufacturer:
-
Family:
Powerpact -
Pole:
2 -
Amp
125 -
Volt:
600 -
Phase:
1
-
Category:
-
Connection:
I-Line Style Plug-In -
Type:
H Frame -
Functions:
LI - Long-Time and Instantaneous -
Protection:
Thermal Magnetic -
AIC Ratings:
18kA@480V
Dimensions
-
Dimensions (HxWxD):
3.39 x 4.09 x 6.42 -
Weight:
4.85 lb
Standards
Product Description - HDA261254 - Schneider Electric Molded Case Circuit Breakers
This Square-D Powerpact circuit breaker is designed for 1-phase (1PH) applications with a 2-pole (2P) configuration. Configured for B & C phase connection, it boasts a high 125A rating at 600V, featuring a standard interrupting capacity of 18kA@480V. UL listed and suitable for reverse fed applications, it ensures reliable electrical protection. The breaker is complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, adhering to Thermal Magnetic principles.
