Product Specifications - HLA36110 - Schneider Electric Molded Case Circuit Breakers
-
Part Number:
HLA36110 -
Manufacturer:
-
Family:
Powerpact -
Pole:
3 -
Amp
110 -
Volt:
600 -
Phase:
3
-
Category:
-
Connection:
I-Line Style Plug-In -
Type:
H Frame -
Functions:
LI - Long-Time and Instantaneous -
Protection:
Thermal Magnetic -
AIC Ratings:
100kA@480V
Dimensions
-
Dimensions (HxWxD):
3.39 x 4.09 x 6.42 -
Weight:
4.85 lb
Standards
Product Description - HLA36110 - Schneider Electric Molded Case Circuit Breakers
Square-D introduces the Powerpact HLA series with a three-phase, 110A molded case circuit breaker featuring an ABC phase connection. Operating at 600V, this breaker ensures reliable protection with a high interrupting capacity of 100kA at 480V. The I-Line Style Plug-In design, UL listing, and non-interchangeable trip settings incorporating Long-Time and Instantaneous functions make it suitable for a range of applications, including reverse fed applications. Thermal Magnetic technology further enhances its performance.
